X-LAB ST5+ E-Bike – Nightfall Black

NEW!

$3,299.00

Enquire RENT WITH STUDIO19
Special Order from Supplier.
Please allow an additional 2-5 business days.

A do-it-all commuter e-bike with an 85Nm mid-drive motor, 619Wh removable battery, rack, mudguards, lights and Apple Find My, in Nightfall Black.

*please be aware of our reutrns policy

Notify me when stock is available

Due to dealer agreement we are unable to ship this bike/frame.

Description

Contact us in store for more information on availability and pricing!

The X-LAB ST5+ in Nightfall Black is a commuter e-bike built to replace short car trips. Its mid-drive motor and 619Wh battery help on hills and with a loaded rack, while 2.4-inch tyres and an 80mm suspension fork smooth out rough roads. It comes ready for daily use, with a rear rack, alloy mudguards, an integrated front light and a Quad Lock phone mount.

Why the X-LAB ST5+ Nightfall Black works for Melbourne commuting

Whether it is Port Melbourne to the CBD, a loop of the Bay Trail or the school and shopping run, the X-LAB ST5+ is set up to do it every day. The 85Nm mid-drive motor gives a natural, pedal-driven feel and flattens out bridges, headwinds off the bay and a full rack of groceries. The 619Wh battery is removable, so you can charge it inside at home or at work, and Apple Find My is built into the bike, so you can track it from your iPhone if it ever goes missing.

Wide 2.4-inch tyres and an 80mm suspension fork take the sting out of tram tracks, cobbles and patchy bike lanes, and 4-piston hydraulic brakes with 180mm rotors give strong, predictable stopping in the wet. The Nightfall Black finish keeps it low-key and hides the grime of a Melbourne winter.

Key features

  • XDS X6 aluminium frame
  • XDS X800 mid-drive motor: 250W rated, 85Nm peak torque
  • 619Wh removable lithium-ion battery
  • Shimano CUES 9-speed, 11-46T cassette
  • Branta 4-piston hydraulic disc brakes with motor cut-off, 180mm rotors
  • Integrated cockpit with colour display and front light
  • Apple Find My built in, plus the X-LAB Bikes app for ride settings and updates
  • MIK-HD rear rack, alloy mudguards and Quad Lock mount included
  • 24.76kg (size L), 150kg maximum load including rider

Sizing, fit and set-up at PMC

The ST5+ comes in sizes S, M and L. Not sure which size suits you? Get in touch with your height and the kind of riding you do and we will recommend the right one. Every e-bike from Port Melbourne Cycles is assembled, checked and set up by our workshop before it goes out, and we can look after servicing and warranty support down the track.

Comparing options? Browse our full range of electric bikes.

Availability

The next delivery from X-LAB’s Australian distributor is due in mid-November 2026. Contact us to reserve your size.

Frame Specs
  • Sizes | S, M, L
  • Colors | Nightfall Black
  • Frame | XDS X6 Aluminium Frame, UDH Compatible
  • Fork | XDS Suspension Fork, Coil Spring, 80mm Travel, 110x15mm Thru-axle
Components
  • Handlebar | Branta Aluminium Integrated, w/ Monitor & Front Light, 680mm, 6° Rise, 15° Backsweep
  • Stem | Branta Aluminium Integrated (bar/stem)
  • Seatpost | XDS Aluminium Seatpost, 31.6mm
  • Saddle | Branta C301
  • Pedals | Flat pedals included
Drivetrain
  • Shifters | Shimano CUES SL-U4000-9R
  • Rear Derailleur | Shimano CUES RD-U4000, 9-Speed
  • Brakes | Branta EC4D E-Bike Brake, 4-Piston, w/ Cut-off Switch, Branta PN28 180mm Rotors
  • Cassette | Shimano CS-LG300 11-46T, 9-Speed
  • Chain | KMC E-GLIDE-S
  • Crankset | Branta Aluminium Crankset, 46T Narrow-wide
Wheels
  • Wheelset | Branta Aluminium E-Bike Wheelset
  • Tyres | CST CTC-06, 27.5 x 2.4, Reflective
Other
  • Extras | MIK-HD Rear Rack, Alloy Mudguards, Quad Lock Mount. Weight 24.76kg (L)
